Optimum Optiturn CNC L34HS808 Advance | CNC3504232

Name: Optimum Optiturn CNC L34HS808 Advance | CNC3504232
Brand: Optimum machinery
SKU: 5213
Availability: InStock

Original price was: R673,076.32.Current price is: R639,999.00.

The Optimum Optiturn CNC L34HS808 is a cutting-edge CNC lathe engineered for high-precision machining and industrial-grade performance. Designed for reliability and accuracy, it features a rigid cast-iron construction, ensuring minimal vibration and maximum stability for smooth operation.

With its powerful spindle motor and advanced CNC control system, this lathe enables efficient and repeatable machining of complex components. The variable speed control allows for fine-tuned adjustments, while its high-precision linear guides enhance accuracy, making it ideal for demanding turning, threading, and contouring applications.

🔹 Key Features:
✔️ Advanced CNC control system for automated precision machining
✔️ High-performance spindle motor for smooth and powerful operation
✔️ Rigid cast-iron frame for durability and vibration resistance
✔️ Variable speed control for flexible operation across materials
✔️ High-precision linear guides for superior accuracy
✔️ Ideal for industrial workshops, production facilities, and precision engineering

Whether you’re handling high-volume production or intricate one-off projects, the Optimum Optiturn CNC L34HS808 offers the speed, accuracy, and reliability required for professional machining.

➡️ Order yours today and experience next-level CNC precision!

1 in stock

Categories: Engineering, Machinery, New Arrivals, Optimum Brand: Optimum machinery

Description

Optimum Optiturn CNC L34HS808 Advance | CNC3504232

Description

OPTIturn L 34HS Sinumerik 808D ADVANCED

CNC controlled flatbed lathe

Technical Specifications
Electrical connection 400 V / 3 Ph ~50 Hz
Total connected value load 6.5 kW
Driving motor 3.7 kW
Torque driving motor 23.6 Nm
Torque on the spindle 40 Nm
Spindle nose (DIN 6350) A2-4
Spindle bore 45 mm
Power of the coolant pump 95 W
Tank capacity 100 l
Centre height 170 mm
Centre width 800 mm
Turning Ø over cross slide 152 mm
Turning Ø over machine bed 340 mm
Bed width 208 mm
Lathe chuck 160 mm
Chuck through hole 40 mm
Spindle speeds
Turret Type Servo / Pneumatic
Number of tool positions 6
WFixture height, width square max. 16 x 16 mm
Fixture diameter drill rod max. 16 mm
Repeatability /- 0.01 mm
Positioning accuracy /- 0.0025 mm
Travel X-axis 185 mm
Travel Z-axis 540 mm
Feed speed X-axis 6’000 mm/min
Feed speed Z-axis 8’000 mm/min
Torque motor X-axis 4 Nm
Torque motor Z-axis 6 Nm
Tailstock seat MT 3
Tailstock – sleeve diameter 45 mm
Tailstock – sleeve travel 120 mm
Length x width x height 1’950 x 1’430 x 1’713 mm
Tank capacity 30 l
Total weight 1’300 kg

Description

CNC controlled flatbed lathe

Precise machining
Braced machine bed made of grey cast iron
Bed guideways inductively hardened (HRC 42-52) and precision ground
Elaborate spindle bearing
Emergency stop push button
Central lubrication
Incremental position encoder for spindle positioning (thread cutting)
Right-handed / left-handed rotation
Ground ball screw spindles
Reference switch
Easy to maintain protective housing
Rear access flap for maintenance purposes
Safety switch at the front sliding door
Feed motors made by SIEMENS
Siemens Sinumerik 808 D on PC free of charge (Computer workstation)
Siemens control SINUMERIK 808D or SINUMERIK 808D ADVANCED

Equipment details:

Turret

for 6 tools

Spindle

Incremental position encoder for spindle positioning (thread cutting)
Large spindle hole

Coolant system

Extractable
Easy disposal of chips

Delivery Information

Mounting bracket for tool changer
Coolant equipment
Machine lamp
Operating tool

Chuck Sold Separately
